Hand filling pump with fill and drain valve½" external thread,
15 mm hose connection,
attainable pressure up to approx. 4 bars,
length 225 mm Learn MoreOur offer is exclusively aimed at corporate clients.
-
Hand filling pump without fill and drain valve½" external thread,
15 mm hose connection,
attainable pressure up to approx. 4 bars,
length 225 mm Learn MoreOur offer is exclusively aimed at corporate clients.
-
Pump set TK5Pressure side:
- thermometer valve with red scale dial thermometer integrated in handle (d = 50 mm), can be pulled off
- integrated check valve, can be opened manually
- DN 25 and DN 32: connection to the left, ½" internal thread for overflow valve or sensor, plugged
Suction side:
- DN 20: pump ball valve, key-actuated
- DN 25 and DN 32: pump ball valve with butterfly handle
Return:
- thermometer valve with blue scale dial thermometer integrated in the handle (d = 50 mm), can be pulled off
- DN 25 and DN 32: connection to the right, ½" internal thread for overflow valve or sensor, plugged
- thread connection
Delivery with 2 nuts and 2 gaskets for a pump (without pump)
Learn MoreOur offer is exclusively aimed at corporate clients.
-
Pump set K5can be completely isolated
Pressure side:
- PAW multivalve, with red butterfly handle
- Check valve, can be opened
- Automatic air passage
- With 2 nuts and gaskets for a pump
(without pump, without dial thermometer)
Suction side:
- PAW pump ball valve, with red butterfly handle
Return:
- PAW multivalve, with red butterfly handle
- Thread connection
Thermometer available as accessory, item number 21711 (red), 21721 (blue) Learn MoreOur offer is exclusively aimed at corporate clients.
-
Charging pump set K1Pressure side:
- PAW pump ball valve, with red butterfly handle
- Flow check valve, can be opened manually
- Automatic air passage
- With 2 nuts and 2 gaskets for a pump DN 25 (without pump)
Suction side:
- PAW pump ball valve, with red butterfly handle
Learn MoreOur offer is exclusively aimed at corporate clients.
-
Pump ball valve (PK)1 x PAW flange (without nut)
1 x internal thread
Material: brass,
with red butterfly handle Learn MoreOur offer is exclusively aimed at corporate clients.
-
Pump ball valve (PKA)1 x PAW flange (without nut)
1 x external thread
Material: brass,
with red butterfly handle Learn MoreOur offer is exclusively aimed at corporate clients.
-
Pump ball valve (PKV)1 x PAW flange (without nut)
1 x external thread
Material: brass,
with red butterfly handle Learn MoreOur offer is exclusively aimed at corporate clients.
-
Pump ball valve (PKAS)1 x PAW flange (without nut)
1 x internal thread
Material: brass
With automatic air passage and check valve (can be opened),
with red butterfly handle Learn MoreOur offer is exclusively aimed at corporate clients.
-
Pump ball valve (PKVS)1 x PAW flange (without nut)
1 x internal thread
Material: brass
With automatic air passage and check valve (can be opened),
with red butterfly handle Learn MoreOur offer is exclusively aimed at corporate clients.
