Accessories DN 32
-
Immersion sleeves ½" ext. threadfor the installation of the temperature sensors (d = 6 mm) in the storage tank, in the collector and the hydraulic separator.
Attention: suitable for ball valves until 2016!
566001: self-sealing with, o-ring, polished brass, for sensor, T = 30 mm
566002: standard, chromed brass, for sensor, T = 60 mm
5660021: standard, chromed brass, with valve extension (25 mm), for sensor, T = 60 mm
566003: standard, chromed copper, for sensor, T = 100 mm
566004: standard, chromed copper, for sensor, T = 150 mm
Learn MoreSolex|SolarBloC®
Solar
thermal
systems
Our offer is exclusively aimed at corporate clients.
Our offer is exclusively aimed at corporate clients.
-
Valves/Fittings
Our offer is exclusively aimed at corporate clients.
Our offer is exclusively aimed at corporate clients.
-
Wall bracket DN 25 - DN 32Galvanised mounting bracket for wall assembly of HeatBloC®s.
Mount HeatBloC®s on mounting bracket for an easy assembly.
Learn MoreHeatBloC®
Heating
technology
Our offer is exclusively aimed at corporate clients.
Our offer is exclusively aimed at corporate clients.
-
PAW actuator SR5Change-over switch for manual / automatic operation,
easy assembly and disassembly thanks to the smart PAW snap-in mechanism,
with 1.5 m cable and mounting set for snap-in assembly on the PAW mixing valve,
for weather-compensated control,
due to the removable scale it is suited for the flow on the right or left side
Technical data
Electrical connection: 230 V / 50 Hz
Input power: 2.5 W
Torque: 5 Nm
Setting time for 90°: 140 s
Learn MoreValves/Fittings
Our offer is exclusively aimed at corporate clients.
Our offer is exclusively aimed at corporate clients.
-
PAW actuator SR10due to the removable scale it is suited for flow on the right or left side,
easy assembly and disassembly thanks to the smart PAW snap-in mechanism,
with 1.5 m cable and mounting set for halting assembly on the PAW mixing valve,
for weather-compensated control, change-over switch for manual / automatic operation
Technical data
Electrical connection: 230 V / 50 Hz
Input power: 3.5 W
Torque: 10 Nm
Setting time for 90°: 140 s
Learn MoreValves/Fittings
Our offer is exclusively aimed at corporate clients.
Our offer is exclusively aimed at corporate clients.
-
PAW Weather compensated controller PWR6Same type as the PAW constant temperature controller PKR6 (art.no. 703601), but for the use of a weather-compensated heating circuit.
The package includes the outdoor sensor, the flow sensor as well as the source sensor. This ensures that the mixing valve or the heating circuit can be operated in an autarkic manner and
without boiler control.
In addition, it is possible to set the room temperature centrally in the flat via a room based remote control (art.no. 1359501).
Learn MoreValves/Fittings
Our offer is exclusively aimed at corporate clients.
Our offer is exclusively aimed at corporate clients.
-
Mounting plate DN 32Components: mounting plate, 2 gaskets, 2 x 2" nut for installation with flat sealings under a modular distribution manifold and for attaching wall brackets
Learn MoreHeatBloC®
Heating
technology
Our offer is exclusively aimed at corporate clients.
Our offer is exclusively aimed at corporate clients.
-
HeatBloC®
Heating
technology
Our offer is exclusively aimed at corporate clients.
Our offer is exclusively aimed at corporate clients.
-
Wall bracket set for modular distribution manifold DN 25-32Components: Mounting equipment
DN 25: Possible wall distance: 150 mm
DN 32: Possible wall distance: 180 mm
For 5-fold modular distribution manifolds, we recommend to use two wall bracket sets. Learn MoreHeatBloC®
Heating
technology
Our offer is exclusively aimed at corporate clients.
Our offer is exclusively aimed at corporate clients.
-
Adapter pipe DN 32Brass, 2 x 2" external thread, flat-sealing, length 180 mm, when an external circulation pump is used to bridge the pump connection.
Learn MoreHeatBloC®
Heating
technology
Our offer is exclusively aimed at corporate clients.
Our offer is exclusively aimed at corporate clients.
